4.DESCRIPTION OF PARAMETERS B-63330EN/03
- 162 -
#7 #6 #5 #4 #3 #2 #1 #0
2248 SRV
[Input type] Setting input
[Data type] Bit
NOTE
After this parameter has been set, the power must be
off turned off then back on for the setting to become
effective.
#0 SRV If the display unit is monochrome (with graphic display capabilities),
the cursor and the title characters on operation screens are displayed:
0 : In a normal way. (Characters are displayed black.)
1 : In reverse video. (Characters are displayed white.)
2249 Cursor/title line background color brightness
[Input type] Setting input
[Data type] Integer
[Valid data range] 0 - 8
If the display unit is monochrome (with graphic display capabilities),
specify the brightness of the background color of the cursor and titles.
If 0 is entered, the standard brightness of the system is assumed.
2250 Background color brightness
[Input type] Setting input
[Data type] Integer
[Valid data range] 0 - 8
If the display unit is monochrome (with graphic display capabilities),
specify the brightness of the background on the screen.
If 0 is entered, the standard brightness of the system is assumed.
2274 Number of the program to start background drawing
2275 Number of the sequence to start background drawing
2276 Number of the program to end background drawing
2277 Number of the sequence to end background drawing
[Input type] Parameter input
[Data type] Integer
[Valid data range] 0 – 99999999
To draw only part of a program, specify drawing start and end blocks
with the program number and sequence number. When the above
