B-63330EN/03 4.DESCRIPTION OF PARAMETERS
- 219 -
5461 Gradient compensation point number a for each axis
5462 Gradient compensation point number b for each axis
5463 Gradient compensation point number c for each axis
5464 Gradient compensation point number d for each axis
NOTE
After this parameter has been set, the power must be
off turned off then back on for the setting to become
effective.
[Input type] Parameter input
[Data type] Integeraxis
[Valid data range] From 0 through 1279 or from 0 through 3071 depending on the
number of controlled axes is less than or equal to 10 or greater than
10, respectively.
Set a gradient compensation point. A compensation point to be set
becomes a compensation number in stored pitch error compensation.
5471 Compensation alpha at gradient compensation point number d for each axis
5472 Compensation beta at gradient compensation point number b for each axis
5473 Compensation gamma at gradient compensation point number c for each axis
5474 Compensation delta at gradient compensation point number d for each axis
NOTE
After this parameter has been set, the power must be
off turned off then back on for the setting to become
effective.
[Input type] Parameter input
[Data type] Integeraxis
[Unit of data] detection unit
[Valid data range] -32767 - 32767
Set a compensation for each compensation point.
