Series 15i/150i - Model A Parameter manual Page 269

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63330EN/03
- 262 -
5977 Rapid traverse rate for orientation
[Input type] Parameter input
[Data type] Realspindle
[Unit of data] degree/min
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 - +240000.0)
Set a rapid traverse rate for analog spindle orientation in the servo
mode (rigid tapping, spindle positioning, and so forth) .
NOTE
Set a rapid traverse rate so that the quantity of errors
is within a range from 128 pulses to 1024 pulses.
5978 Time constant for orientation
[Input type] Parameter input
[Data type] Integerspindle
[Unit of data] msec
[Valid data range] 0 - 4000
Set a time constant for analog spindle orientation in the servo mode
(rigid tapping, spindle positioning, and so forth) .
5979 FL feedrate for orientation
[Input type] Parameter input
[Data type] Realspindle
[Unit of data] degree/min
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 - +240000.0)
Set an FL feedrate for analog spindle orientation in the servo mode
(rigid tapping, spindle positioning, and so forth) .
NOTE
Set an FL feedrate rate so that the quantity of
errors is within a range from the effective area to
1024 pulses.
5980 Grid shift value for orientation
[Input type] Parameter input
[Data type] Integerspindle
[Unit of data] detection unit
[Valid data range] -2048 - 2048
Set a grid shift value from the orientation stop position of the analog
spindle in the servo mode (rigid tapping, spindle positioning, and so
forth) .
