4.DESCRIPTION OF PARAMETERS B-63330EN/03
- 368 -
7793 Limit for normal-direction control axis rotation
[Input type] Parameter input
[Data type] Real
[Unit of data] degree
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] 1 - 999999999
A specified limit functions as a limit for ignoring the angular
displacement of the normal-direction control axis. The parameter
means as follows:
When the angular displacement calculated in normal-direction control
is less than the limit specified in this parameter, the block that
specifies the calculated angular displacement is not inserted in the
program. The ignored angular displacement is added to the angular
displacement to be calculated next, which in turn is compared with
the parameter value.
Note)
- When an angle of 360 degrees or larger is specified in this
parameter, the block that specifies the angular displacement is
not inserted in the program.
- When an angle of 180 degrees or larger is specified in this
parameter, the block that specifies the angular displacement is
not inserted in the program unless circular interpolation is
performed with an angle of 180 degrees or larger.
7794 Limit of the travel distance moved using the normal-direction angle in the
previous block
[Input type] Parameter input
[Data type] Real
[Unit of data] mm, inch (input unit)
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] 1 - 999999999
Set a limit on the travel distance moved using the normal-direction
angle of the previous block without modification.
7795 Retract feedrate
[Input type] Parameter input
[Data type] Real
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 - +240000.0)
Set a feedrate for retraction along each axis.
