Series 15i/150i - Model A Parameter manual Page 211

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63330EN/03
- 204 -
#7 #6 #5 #4 #3 #2 #1 #0
5210 OT2
[Input type] Setting input
[Data type] Bitaxis
#0 OT2 Specifies whether to check stored stroke limit 2 for each axis (valid
when OUT is set to 0.) .
0: Stored stroke limit 2 is not checked for each axis.
1: Stored stroke limit 2 is checked for each axis.
NOTE
If OUT (bit 0) of parameter No. 5200 is set to 1,
stored stroke limit 2 is checked for all the
controlled axes.
5220 Positive (+) direction coordinate of stored stroke limit 1 of each axis I
[Input type] Parameter input
[Data type] Realaxis
[Unit of data] mm, inch, degree (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
table (A) )
(When the increment system is IS-B, -999999.999 - +999999.999)
Set the coordinate in the positive-direction machine coordinate system
of stored stroke limit 1 for each axis.
5221 Negative (-) direction coordinate of stored stroke limit 1 of each axis I
[Input type] Parameter input
[Data type] Realaxis
[Unit of data] mm, inch, degree (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
table (A) )
(When the increment system is IS-B, -999999.999 - +999999.999)
Set the coordinate in the negative-direction machine coordinate
system of stored stroke limit 1 for each axis.
5222 Positive (+) direction coordinate of stored stroke limit 2 of each axis
[Input type] Setting input
[Data type] Realaxis
[Unit of data] mm, inch, degree (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
table (A) )
(When the increment system is IS-B, -999999.999 - +999999.999)
Set the coordinate in the positive-direction machine coordinate system
of stored stroke limit 2 for each axis.
