Manual Guide i Operators manual Page 141

Operators manual
B-63874EN/05 OPERATION 5.DETAILED DESCRIPTIONS ABOUT ENTERING ARBITRARY FIGURES
- 119 -
ELEMENT (INPUT DATA) (Note 1)
Data item Meaning
D HEIGHT/DEPTH Height or Depth from Base position to cutting surface
Remarks) This item is displayed in Contouring,
Pocketing, Grooving and Emboss
machining.
W GROOVE WIDTH Groove width (Positive value)
Remarks) This item is displayed in Grooving.
P FIGURE ATTRIBUTE [RIGHT] : The right side of an entered figure as
cutting
[LEFT] : The left side of an entered figure as cutting
Remarks) This item is displayed in Open figure of
Contouring.
Y ROTATION AXIS NAME [C] : The rotation axis is the C axis.
[A] : The rotation axis is the A axis (No.27000#1=1)
[B] : The rotation axis is the B axis (No.27000#2=1)
[E] : The rotation axis is the E axis (No.27000#3=1)
Remarks) This item is displayed when the parameter
No.27000#0=1.
NOTE
1 ‘INPUT DATA’ means the items, which are
displayed on the input data window in editing or
altering.
2 Select, with a figure type for a start point, which
milling operation is to use an arbitrary figure. Data
to be entered for the start point varies depending
on what figure type is selected. For details, see
descriptions about the respective milling types.
ELEMENT (OUTPUT DATA) (Note 3)
Data item Meaning
T FIGURE ATTRIBUTE [1] : Used as a figure in facing
[2] : Used as an outer-perimeter figure in contouring
[3] : Used as an inner-perimeter figure in contouring and
emboss machining or a figure in pocketing
[4] : Used as a figure in grooving
(input value)
H START POINT Z Z coordinate of the start point (input value)
V START POINT C C coordinate of the start point (input value)
I START POINT (Z
AXIS)
Z coordinate of an arc end point (calculation result)
J START POINT (C
AXIS)
C coordinate of an arc end point (calculation result)
B BASE POSITION Position of the machining surface (input value)
L HEIGHT/DEPTH Height or Depth from Base position to cutting surface
Remarks) This item is displayed in Contouring,
Pocketing, Grooving and Emboss machining.
(input value)
D GROOVE WIDTH Groove width (Positive value)
Remarks) This item is displayed in Grooving.
(input value)
