B-63874EN/05 CYCLE MACHINING TYPES 1.MILLING

- 333 -

NOTE

7 In the input data item of “CUT ANGLE” of

Pocketing Rough (G1040) and Bottom Finish

(G1041), when the machine is 2 axes of Maximum

simultaneously controlled axes, please sure not to

set the data.

(If the data is set, the alarm 15 occurred during

execution of Cycles.)

8 The motions go back to the start point where the

machining cycle started after completing the all

cycle motions.

(It is possible not to go back to the start point when

the parameter No. 27002#7 is set to 1.)

9 Cycle machining cannot be performed in any of

control modes of the high-speed and high-precision

functions (commands for advanced preview

control, AI advanced preview control, AI contour

control, AI nano contour control, high-precision

contour control, AI high-precision contour control,

and AI nano high-precision contour control). To

perform cycle machining, control mode must be

canceled.

10 On the CNC for lathe turning with G-code system B

or C, when cycle machining is specified, G90 must

be specified in advance to make a switchover to

the absolute coordinate system. For hole

machining by turning (with the tool rotated), G98

(initial level return) or G99 (R position level return)

must be specified in advance.

11 On the CNC for milling, when cycle machining is

specified, a switchover to G90 (absolute command)

occurs internally. Therefore, G91 must be specified

if incremental commands are used after cycle

machining.
