27383 F MIL TIP LENGTH
(2-word type, FANUC standard settings=0)
F MIL TIP LENGTH : Tip length when animate face mill tool
Input unit :
mm input (0000#2=0) : 0.001(mm)
inch input (0000#2=1) : 0.0001(inch)
Remarks)
If 0 is set in case of metric input (0000#2=0), default data will be
63mm.
If 0 is set in case of inch input(0000#2=1), default data will be
2.4803inch.
A.4.7 Parameter for Machining Simulation (Animated)
27390 M-CODE AVERAGE TIME
(2-word type, FANUC standard settings=0)
M-CODE AVERAGE TIME
: Execution time of averaged M code
This parameter is used for calculating machining time.
data unit : 10(msec)
valid data range : 0-99999999
27391 S-CODE AVERAGE TIME
(2-word type, FANUC standard settings=0)
S-CODE AVERAGE TIME
: Execution time of averaged S code
This parameter is used for calculating machining time.
data unit : 10(msec)
valid data range : 0-99999999
27390 T-CODE AVERAGE TIME
(2-word type, FANUC standard settings=0)
T-CODE AVERAGE TIME
: Execution time of averaged T code
This parameter is used for calculating machining time.
data unit : 10(msec)
valid data range : 0-99999999
