Manual Guide i Operators manual Page 205

Operators manual
B-63874EN/05 OPERATION 9.MACHINING SIMULATION AND DRAWING DURING MACHINING
- 183 -
9.5 MACHINING SIMULATION (ANIMATED) (FOR Series 30i)
During machining, animated simulation can be performed for another
program.
The terms related to operation and drawing for tool path drawing
described in Section 9.4 are applicable. See Section 9.4.
With Series 30i MANUAL GUIDE i, machining simulation
(animated) can be performed in the MEM mode and EDIT mode. The
operation for displaying the machining simulation screen in each
mode is the same as for tool path drawing. See Section 9.4.
In order to distinguish the executing state of the program, machining
custom macro program can refer to the following system variable
#3010.
System variable Value Executing State
0 Normal condition(Other than the following
status)
#3010
-1 Executing machining simulation(Animated,
Tool Path)
9.5.1 Program Selection Operation and Other Operations in
Machining Simulation (Animated)
The operations are the same as those operations performed for tool
path drawing described in Section 9.4. See Section 9.4.
9.5.2 Execution Operations in Machining Simulation (Animated)
On the 1st page soft keys, you can perform operations related to
execution in machining simulation (animated). The operations of
[REWIND], [START], [PAUSE], [SINGLE], and [STOP] are the
same as the operations in machining simulation (tool path). For details,
see Subsection 9.2.3.
[INIT] : Initialize the machined blank used for animation.
[CUTDSP] : Lets you switch between 1/4 workpiece and entire
periphery for rod blanks and drilled rod blanks. Before
starting animated simulation, be sure to switch if
necessary.
[INTERF] : Lets you select whether to make an interference check
during animated simulation. If an interference check is
enabled, a warning is displayed when the tool tip
collides with a workpiece during rapid traverse, and the
GRPOFFTLPATH
INTERF
CUTDSP
INIT
STOP
PAUSE
SINGLE
START
REWIND
