Manual Guide i Operators manual Page 802

Operators manual
A.PARAMETERS APPENDIX B-63874EN/05
- 780 -
NOTE
1 When the parameter No.27003 is set, please sure
to push [F] key on NOW LOADING screen after
Power ON. The necessary parameters are set
automatically. (When the necessary parameters
are set, the message of “NOW SETTING
PARAMETERS” is displayed on the left side of
NOW LOADING screen.)
2 By setting the parameter No.27003, the following
parameters related to display are set
autoimatically.
No.14702#1
Spindl select
No.27000#1
Hole select
No.27000#4
Face pos-M
No.27100#4
Face pos-T
No.27000#6
Coord conv
No.27001#0,#1
Rot. axis nam
No.27004#0
Menu 1
No.27004#1
Menu 2
No.27003 #0=1
0 0 0 0 1 0 1 0
No.27003 #1=1
0 0 0 0 0 0 0 0
No.27003 #2=1 0 0 0 0 0 0 0 0
#7 #6 #5 #4 #3 #2 #1 #0
27004 MM2 MM1 MM0
If the machine configuration does not meet the parameter No.27003 or
No.27103, this parameter is used to display the optimum menu on the
screen.
MM0 1 : The following menus are displayed.
• Hole Machining (G1000 to G1006) or (G1110 to G1114)
• Facing (G1020 to G1021)
• Contouring (G1030 to G1033)
• Pocketing (G1040 to G1043)
• Grooving (G1050 to G1053)
• XY-plane : Free figure (G1200 to G1206)
• XY-plane : Hole position (G1210 to G1217)
• XY-plane : Fixed form figure (G1220 to G1223)
MM1 1 : The following menus are displayed.
• Hole Machining (G1000 to G1006) or (G1110 to G1114)
• Facing (G1020 to G1021)
• Contouring (G1030 to G1033)
• Pocketing (G1040 to G1043)
• Grooving (G1050 to G1053)
• C-axis Grooving (G1056)
• XC-plane : Free figure (G1500 to G1506)
• XC-plane : Fixed form figure (G1520 to G1523)
• XC-plane : C-axis figure (G1570 to G1573)
• ZC-plane : Free figure (G1600 to G1606)
• ZC-plane : C-axis figure (G1670 to G1673)
