2.TURNING CYCLE MACHINING TYPES B-63874EN/05

- 490 -

DETAIL

Data item Meaning

S CUT DEPTH DIRECTION As to X axis Cut direction,

[-X] : Cuts in the –X direction.

[+X] : Cuts in the +X direction.

Remark) This data item is enable when the

parameter No.27100#0 = 1. (COPY)

X POCKET CUTTING [CUT] : Cuts a pocket. (initial value)

[NOTHIN] : Does not cut a pocket.

Remark) This data item is enable when the

parameter No.27100#1 = 1.

Y OVERHANG CUTTING [CUT] : Cuts an overhang. (initial value)

[NOTHIN] : Does not cut an overhang.

Remark) This data item is enable when the

parameter No.27100#1 = 1.
