B-63874EN/05 OPERATION 18.HANDLING LARGE PROGRAMS

- 291 -

18.1 SETTING A MAXIMUM PROGRAM SIZE THAT CAN BE

HANDLED

In parameter No. 14795, specify a maximum allowable memory size

to be used for program management.

Parameter

<1> No.14795#4 = 0 & No.14795#5 = 0

Set the maximum allowable program size to 250K bytes.

<2> No.14795#4 = 1 & No.14795#5 = 0

Set the maximum allowable program size to 500K bytes.

<3> No.14795#4 = 0 & No.14795#5 = 1

Set the maximum allowable program size to 1M bytes.

<4> No.14795#4 = 1 & No.14795#5 = 1

Set the maximum allowable program size to 2M bytes.

* A size of 200K bytes represents about 100,000 characters (4,000

blocks) when one block consists of 25 characters on average.

CAUTION

To specify a maximum allowable memory size

greater than 250K bytes in parameter No. 14795,

set an appropriate value in parameter No. 8781

(DRAM size that can be used by a C language

application).

To increase the DRAM size, the custom capacity

option is separately required.

* If the DRAM size is increased by 1M bytes by

using parameter No. 8781, about 500,000

characters (about 20,000 blocks) can be

increased as a guideline when one block consists

of 25 characters on average.

Restrictions

<1> If a large program is selected, the time required for switching

from the NC screen to MGi screen increases.

<2> If a large program is selected, a longer time is required to move

the program cursor as the program number increases.
