B-63874EN/04 MULTI-PATH LATHE FUNCTIONS 3.PROCESS LIST EDITING FUNCTION

- 605 -

3.5 EDITING OPEARTIONS

The following operations are available on each cell.

Operation Description

INSCEL Insert process to the upper part of the specified cell.

DELCEL Delete the specified cell.

CPYCEL Copy the specified cell to the specified position.

MOVCEL Move the specified cell to the specified position.

RENAME Modify the comment of the specified cell.

EDTPRG Edit the program including the specified cell.

STWAIT * Set the waiting to the specified cell.

CLWAIT * Release the specified waiting.

STTRNS * Set the transfer to the specified cell.

CLTRNS * Release the specified transfer.

ADD / * Add the optional block skip.

DEL / * Delete the optional block skip.

NOTE

Operations marked with * cannot be used on

1-path lathe.
