B-63874EN/05 APPENDIX A.PARAMETERS

- 805 -

27303 MTYPE

(Byte type, FANUC standard settings = 0)

MTYPE : Type of machine mechanism

Type Controlled rotary axis Parameter setting for the axis

Without a rotary axis

With a tool rotary axis

Parameter No.14178 is a tool rotary

axis.

With a workpiece table rotary

axis

Parameter No.14178 is a workpiece

table rotary axis.

NOTE

1 No. of workpiece rotated axis (usually C-axis) is

set to the parameter No.14717. In the case of

machine mechanism type=1, this parameter must

not be set to workpiece table rotary axis No.

2 Drawing of machining simulation is not available

for a machine which takes a tool rotary axis with a

workpiece table rotary axis.

3 Drawing of machining simulation is not available

for a machine which has the roatry axis slant for

the basic three axis.

4 Machine mechanism type=2(With a workpiece

table rotary axis) is not available with multi-path

system or with a subspindle.

5 The axis to set to the parameter No.14718 is only

a rotary axis about Y axis.

27305 TBLDISTX

(2-word type, FANUC standard settings = 0)

TBLDISTX : In the case that type of machine mechanism is type 1(With a

workpiece table rotary axis), distance (X-axis) from the rotary center

point to the rotary standard point of drawing blank figure. The

direction of + X axis is “+” for this data.
