Manual Guide i Operators manual Page 433

Operators manual
B-63874EN/05 CYCLE MACHINING TYPES 1.MILLING
- 411 -
NOTE
1 Tab ‘TOOL COND.’ is enabled when bit 0 (TLG) of
parameter No. 27002 = 1.
2 The operator ordinarily sets the above data on the
tab of ‘TOOL DATA’ in Tool Offset window.
Therefore, it is not necessary to display the tab
‘TOOL COND.’
CUT COND.
Data item Meaning
T* BOTTOM THICKNESS Cutting allowance of the bottom in side face
machining. The blank is regarded as 0. (radius
value, positive value)
S* SIDE THICKNESS Cutting allowance of the side face. The blank is
regarded as 0. (radius value, positive value)
Remark) When both the side surplus thickness and
bottom surplus thickness are omitted, an
entire pocket area is cut.
L CUT DEPTH OF RADIUS Depth of cut on the side face (tool radius direction)
per cutting operation (radius value, positive value)
J CUT DEPTH OF AXIS Depth of cut in the tool axis direction per cutting
operation (radius value, positive value)
K* SIDE FINISH AMOUNT Finishing allowance on the side face. The blank is
regarded as 0. (radius value, positive value)
H* BOTTOM FINISHI AMT. Finishing allowance at the bottom in side face
machining. The blank is regarded as 0. (radius
value, positive value)
F FEED RATE- SING.CUT Feedrate applicable when only the one-side cutter
portion of an end mill is used for cutting. This
feedrate is used for cutting in retract operation and
on the side face other than initial cutting.
V FEED RATE- BOTH.CUT Feedrate applicable when the entire front side of an
end mill is used for cutting. This feedrate is used for
initial cutting.
E FEED RATE- AXIS Feedrate applicable when cutting is performed in the
tool axis direction toward the bottom of a side face
being machined
DETAIL
Data item Meaning
W UP CUT/DOWN CUT
[UP CUT] : Performs machining in up-cut mode,
assuming that the tool is rotating
clockwise.
[DWNCUT] : Performs machining in down-cut
mode, assuming that the tool is
rotating clockwise.
(COPY)
