9.MACHINING SIMULATION AND DRAWING DURING MACHINING OPERATION B-63874EN/05

- 182 -

9.4.2 Execution Operations in Machining Simulation (Tool Path)

On the 2nd page soft key, you can perform operations related to

execution in machining simulation (tool path).

[REWIND] : Return to the beginning of the machining program

selected for machining simulation.

[START] : Start machining simulation for the currently selected

machining program.

[PAUSE] : Stop machining simulation temporarily.

[SINGLE] : Cause a single-block stop when machining simulation is

performed in the continuous mode. When machining

simulation is in the stopped state, this soft key starts

machining simulation in the single-block mode.

[STOP] : End machining simulation.

[NODISP] : From the block immediately after this soft key is

pressed, suppress tool path drawing. Tool path drawing

is not performed until [DISP] is pressed next.

[DISP] : From the block immediately after this soft key is

pressed, start drawing of the tool path.

Remark) Only necessary tool path portions can be drawn by

using [DISP] and [NODISP].

[CLEAR] : Erase the tool path drawn so far. Tool path drawing

immediately after this soft key is pressed is displayed.

NOTE

1 By setting bit 0 (PRC) of parameter No. 27310 to 1,

[PAUSE] can be changed to [PROCES] (for temporarily

stopping machining simulation at a block specifying

M01;).

9.4.3 Scaling, Movement, and Other Operations in Machining

Simulation (Tool Path)

The operations are the same as those operations performed with Series

16i/18i/21i-MODEL B. For details, see Subsection 9.2.3.

GRPOFFANIME

CLEAR

NODISP

DISP

STOP

PAUSE

SINGLE

START

REWIND
