Manual Guide i Operators manual Page 511

Operators manual
B-63874EN/05 CYCLE MACHINING TYPES 2.TURNING
- 489 -
CUT COND.
Data item Meaning
D* Z-AXIS FINISH AMT. Finishing allowance in the Z-axis direction. The
blank is regarded as 0. (radius value, positive value)
F CUT DIRC.FEEDRATE Feedrate applicable when the tool cuts in the
workpiece radius direction (positive value)
E CUT DEPTH FEEDRATE Feedrate applicable when the tool cuts in the Z-axis
direction (positive value)
V CUT RISE FEEDRATE Feedrate applicable when the tool cuts up in the
direction of retraction from the workpiece (positive
value)
DETAIL
Data item Meaning
K 1ST OVERRIDE Feedrate override value for the first cut. Specify an
override value in steps of 1%. The default is 100%.
(1 - 200, positive value)
Remark) This data item is used, for example, to cut
the black coating of a cast workpiece.
W CUT RISE METHOD [SPEED] : The tool retracts by a distance specified
with ESCAPE AMOUNT in the XZ
direction immediately after cutting.
[CUT] : The tool retracts by a "retract" distance"
after cutting along the figure.
(COPY)
U ESCAPE AMOUNT Distance by which the tool retracts from a cutting
surface after each cut (radius value, positive value)
Remark) By referring to the parameter No. 27128
(minimum clamp value), the system sets
the data as an initial value.
L X-AXIS CLEARANCE Distance between a blank and machining start point
(approach point) in the X-axis direction (radius
value, positive value)
Remark) By referring to the parameter No. 27129
(minimum clamp value), the system sets
the data as an initial value.
M Z-AXIS CLEARANCE Distance between a blank and machining start point
(approach point) in the Z-axis direction (radius value,
positive value)
Remark) By referring to the parameter No. 27130
(minimum clamp value), the system sets
the data as an initial value.
Z APROCH MOTION [Z→X] : From the current position to the
machining start point, the tool moves in
the Z-axis direction and then in the
X-axis direction. (initial value)
[X→Z] : From the current position to the
machining start point, the tool moves in
the Z-axis direction and then in the
X-axis direction.
[2 AXES] : From the current position to the
machining start point, the tool moves
simultaneously in the X- and Z-axis
directions.
