A.PARAMETERS APPENDIX B-63874EN/05
- 778 -
A.3 PARAMETERS FOR MILLING CYCLE MACHINING
A.3.1 Parameters for Milling Cycles in General
These parameters are for the settings for milling cycles in general.
#7 #6 #5 #4 #3 #2 #1 #0
27000 MC7 MC6 MC5 MC4 MC3 MC2 MC1 MC0
MC0 0 : In ZC plane cycle output, G02/G03 are inverted.
1 : In ZC plane cycle output, G02/G03 are not inverted.
MC1 0 : The hole machining menu has hole machining items for M.
Remark) Refer to “1.1 Hole Machining by Milling”.
1 : The hole machining menu has hole machining items for T.
Remark) Refer to “1.2 Hole Machining by Turning”.
MC2 0 : In XC plane cycle output, G12.1/G13.1 are not output.
1 : In XC plane cycle output, G12.1/G13.1 are output.
Remark) Refer to the paragraph of XC plane figure of Facing,
Contouring, Pocketing or Grooving.
MC3 0 : In ZC plane cycle output, G07.1 is not output.
1 : In ZC plane cycle output, G07.1 is output.
Remark) Refer to the paragraph of ZC plane figure of Facing,
Contouring, Pocketing or Grooving.
MC4 0 : In cycle input screens, the tab of [FACE POSIT] for end face position
is not displayed.
1 : In cycle input screens, the tab of [FACE POSIT] for end face position
is displayed.
Remark) Refer to “1.8 Rear End Facing by Milling”.
MC5 0 : In the soft-key of [START],[CYCLE],[END] and [FIGURE], the
icons for Milling are displayed.
1 : In the soft-key of [START],[CYCLE],[END] and [FIGURE], the
icons for Turning are displayed.
MC6 0 : In [START] menu screens, the tab of [COORD CONV] is displayed.
1 : In [START] menu screens, the tab of [COORD CONV] is not
displayed.
Remark) Refer to “III-3. Slant Face Machining (coordinate
conversion)”.
MC7 0 : The tab of [EMBOSSING] is not displayed on the cycle machining
menu.
1 : The tab of [EMBOSSING] is displayed on the cycle machining menu.
