B-63874EN/05 CYCLE MACHINING TYPES 1.MILLING

- 401 -

DETAIL

Data item Meaning

C CLEARANCE OF AXIS Distance between the surface of a blank being

machined and a cutting start point (point R) in the

tool axis direction (radius value, positive value)

Remark) By referring to the parameter No.27009

(minimum clamp value), the system sets

the data as Initial value.

P APPROACH TYPE [ARC] : Approaches a side face along an arc.

[TANGEN] : Approaches a side face along the

straight line tangent to the first figure

in side face cutting.

[VERTIC] : Approaches a side face along the

straight line normal to the first figure in

side face cutting.

(COPY)

R APPROACH RAD./DIST. Radius when [ARC] is specified.

Straight line length when [TANGEN] or [VERTIC]

is specified. (radius value, positive value)

Remark) By referring to the parameter No.27010

(minimum clamp value), the system sets

the data as Initial value.

A* APPROACH ANGLE Center angle of the arc when [ARC] is specified.

The default is 90 degrees. (positive value)

Remark) This data item is indicated only when

[ARC] is selected for APPROACH TYPE.

(COPY)

Q ESCAPE TYPE [ARC] : Retracts from a side face along an

arc.

[TANGEN] : Retracts from a side face along the

straight line tangent to the last figure

in side face cutting.

[VERTIC] : Retracts from a side face along the

straight line normal to the last figure in

side face cutting.

(COPY)

X ESCAPE RAD./DIST. Radius when [ARC] is specified.

Straight line length when [TANGEN] or [VERTIC]

is specified. (radius value, positive value)

Remark) By referring to the parameter No.27010

(minimum clamp value), the system sets

the data as Initial value.

Y* ESCAPE ANGLE Center angle of the arc when [ARC] is specified.

The default is 90 degrees. (positive value)

Remark) This data item is indicated only when

[ARC] is selected for ESCAPE TYPE.

(COPY)
