Manual Guide i Operators manual Page 644

Operators manual
3.PROCESS LIST EDITING FUNCTION MULTI-PATH LATHE FUNCTIONS B-63874EN/04
- 622 -
3.5.9 Assign of Transfer
Function
• Set the transfer between the process.
• In NC program,
Start process block : G1992 Sx (xxxx)
Q0 Mxxx (Pxx) will be set to above block,
End process block : G1993
Mxxx (Pxx) will be set to above block.
Basic Operation
1. Press [STTRNS]. (Cursor position pretermission)
2. Move cursor to the source transfer, and press [SELECT].
3. Move cursor to the destination transfer, and press [SELECT].
4. Press [STTRNS].
5. Press [RETURN], and release set transfer mode.
N
10 ROUGH
*N20 FINE
TURRET 1 TURRET 2
N
10 DRILL
N
20 TAP
% %
Add “*” to the top of the selected
cell.
N
10 ROUGH
N
20 FINE
TURRET 1 TURRET 2
N
10 DRILL
N
20 TAP
% %
The software key array changes into
set waiting mode.
N
10 ROUGH
*N20 FINE
TURRET 1 TURRET 2
*N10 DRILL
N
20 TAP
% %
Add “*” to the top of the selected
cell.
Moreover background color of the
source waiting cell become green.
Press either [STTRNS] or
[CANCEL].
(When finished normally, selected state will
be released automatically.)
N
10 ROUGH
N
20 FINE
TURRET 1 TURRET 2
N
10 DRILL
N
20 TAP %
%
