1.MILLING CYCLE MACHINING TYPES B-63874EN/05

- 414 -

DETAIL

Data item Meaning

W UP CUT/DOWN CUT

[UP CUT] : Performs machining in up-cut mode,

assuming that the tool is rotating

clockwise.

[DWNCUT] : Performs machining in down-cut

mode, assuming that the tool is

rotating clockwise.

(COPY)

B CLEARANCE OF RADIUS Distance between the side face and a tool retract

position in the tool radius direction (radius value,

positive value)

Remark1) When one pocket cutting operation is

completed, the tool performs a retract

operation in the tool axis direction from

the side face of the pocket by this

clearance amount.

Remark2) By referring to the parameter No.27009

(minimum clamp value), the system sets

the data as Initial value.

C CLEARANCE OF AXIS Distance between the surface of a blank being

machined and a cutting start point (point R) in the

tool axis direction (radius value, positive value)

Remark) By referring to the parameter No.27009

(minimum clamp value), the system sets

the data as Initial value.

Z APROCH MOTION [2 AXES] : When moving from the current position

to the machining start point, the tool first

moves in the machining plane in

two-axis synchronous operation and

then moves along the tool axis. (initial

value)

[3 AXES] : The tool moves from the current

position to the machining start point in

three-axis synchronous operation.
