B-63874EN/05 APPENDIX C.MANUAL GUIDE i SETUP METHOD
- 833 -
C.4 PARAMETER SETTING
C.4.1 Lathe
Set the parameters of the cells in the first path and set those
of cells in each path in case of multi path lathe and lathe with
compound machining function.
(1) Set following parameters for MANUAL GUIDE i Basic function.
No. Value note
3103#3 1
CNC ignores [HELP] key during displaying C
executor screen in open CNC.
(It is necessary in Series 30i.)
3106#2 1
[NEXT DISTANCE] display is available in single
block mode
It sumultaneously enables to look ahead 1 block.
So if you stop the execution by SINGLE BLOCK
signal, then edit the next block and re-start, the
block before editting is executed.
3206#6 1
No.3106#6, position display change for 3D
conversion mode, is effective in MANUAL GUIDE i
screen
3112#0 0
Servo wave display is not available
(It is necessary in Series 30i.)
3201#6 1
M02,M30,M99 are not regarded as the end of
resister
8661 40
SRAM size for application’s backup variables
(40KB)
(It is necessary in Series 30i.)
8662 23
SRAM size for application’s backup (23KB)
(It is necessary in Series 30i.)
8650#1 1
not switched to alarm screen automatically during
displaying C executor screen
8650#0 1
C executor transfer [RESET] key code to
application
8701#6 1
TV check is skipped during edit operation
(It is necessary in Series 30i.)
8701#4 1
Vacant value of P code variables can be read.
(It is necessary in Series 30i.)
8781 0
DRAM size for user program of C executor must
be zero
(It is necessary in Series 30i.)
9000#0 0 Debug parameter for macro program must be zero
14700#7=0 0
Enable to run MANUAL GUIDE i
14794-14795 *
Assign function key for start MANUAL GUIDE i
9071 90
P code number for MANUAL GUIDE i
( in Series 30i with optional function)
9072 1
Block number for dealing with Macro sentence
continuously in Execute Macro program for
MANUAL GUIDE i.
( in Series 30i with optional function)
*
