B-63874EN/05 CYCLE MACHINING TYPES 2.TURNING

- 555 -

CORNER INFO

Data item Meaning

I CORNER TYPE-3 For corner (3)

[NOTHIN] : Specifies neither chamfering nor

corner rounding (initial value).

[CHAMFR] : Specifies chamfering.

[ARC] : Specifies corner rounding.

J CORNER SIZE Chamfer amount or corner radius (radius value,

positive value)

Remark) This data item is indicated only when

[CHAMFR] or [ARC] is selected for

CORNER TYPE-3.

Q CORNER TYPE-4 For corner (4)

[NOTHIN] : Specifies neither chamfering nor

corner rounding (initial value).

[CHAMFR] : Specifies chamfering.

[ARC] : Specifies corner rounding.

R CORNER SIZE Chamfer amount or corner radius (radius value,

positive value)

Remark) This data item is indicated only when

[CHAMFR] or [ARC] is selected for

CORNER TYPE-4.

REPEAT

Data item Meaning

M* GROOVE NUMBER Number of grooves of the same figure to be

machined. The blank is regarded as 1. (positive

value)

S PITCH Distance between the reference positions of two

adjacent grooves (radius value, positive value)

W* PITCH DIRECTION [-X] : Places a second and subsequent grooves

in the -X direction (initial value).

[+X] : Places a second and subsequent grooves

in the +X direction.
