6.MANUAL GUIDE i SIMULATOR FOR THE PERSONAL COMPUTER GENERAL B-63874EN/05

- 26 -

6.8.3.1 [Simulator_MachineSetting_MaxNumber] section

Key name : maxnumber

Outline : Code a maximum subscript value for the simulator

definitions to be found in the file.

Character string to be set : Maximum subscript number to be found

Explanation : Code a maximum subscript value for the simulator

definitions in the simulator definition file. A search

for a simulator definition is made until n of the

Simulator_MachineSettingn section reaches

maxnumber. A found simulator definition is displayed

in a selection dialog box.

6.8.3.2 [Simulator_MachineSettingn] section

Key name : name

Outline : Code the name assigned to a simulator definition.

Character string to be set : Arbitrary

Explanation : Code the name assigned to a simulator definition. The

character string coded here is displayed in the simulator

definition selection dialog box displayed when the MGi

manager is started.

Key name : cnctype

Outline : Code a CNC model.

Character string to be set : "FS16i", "FS18i", "FS21i", "FS30i"

Explanation : Code the model of the CNC. If an attempt to read a

file described below such as a From.dat file fails, the

model coded in the MGi manager ini file is used.

Key name : displaytype

Outline : Code a display unit type.

Character string to be set : "10.4", "15"

Explanation : Code the type of the display unit. At present, specify

"10.4" or "15".

Key name : pathtype

Outline : Code a path type.

Character string to be set : "T", "TT", "TTT", "M", "TM", etc.

Explanation : Code a path type. Specify "T" for T series single-path

control. Specify "TT" for T series two-path control.

Specify "M" for the M series. Specify "TM" for

compound control.

Key name : cnctype_title

Outline : Set a CNC model name for display.

Character string to be set : Arbitrary

Explanation : Set a CNC model name for display.
