Manual Guide i Operators manual Page 790

Operators manual
A.PARAMETERS APPENDIX B-63874EN/05
- 768 -
A.2.16 Settings for Current Position Display
14799 DS1AXS
DS1AXS 0 : The first controlled axis is displayed in display area 1.
≠0 : Number of the controlled axis to be displayed in display area 1.
14800 DS2AXS
DS2AXS 0 : The second controlled axis is displayed in display area 2.
≠0 : Number of the controlled axis to be displayed in display area 2.
14801 DS3AXS
DS3AXS 0 : The third controlled axis is displayed in display area 3.
≠0 : Number of the controlled axis to be displayed in display area 3.
14802 DS4AXS
DS4AXS 0 : The fourth controlled axis is displayed in display area 4.
≠0 : Number of the controlled axis to be displayed in display area 4.
14803 DS5AXS
DS5AXS 0 : The fifth controlled axis is displayed in display area 5.
≠0 : Number of the controlled axis to be displayed in display area 5.
14804 DS6AXS
DS6AXS 0 : The sixth controlled axis is displayed in display area 6.
≠0 : Number of the controlled axis to be displayed in display area 6.
14805 DS7AXS
DS7AXS 0 : The seventh controlled axis is displayed in display area 7.
≠0 : Number of the controlled axis to be displayed in display area 7.
14806 DS8AXS
DS8AXS 0 : The eighth controlled axis is displayed in display area 8.
≠0 : Number of the controlled axis to be displayed in display area 8.
