C.MANUAL GUIDE i SETUP METHOD APPENDIX B-63874EN/05

- 840 -

14795#0=1: [CUSTOM](AUX screen) key is assigned for start

(No.8652#5 must be set to 1 in case macro screen does

not exist)

#1=1: [CUSTOM](MCR screen) key is assigned for start

(No.8652#6 must be set to 1 in case macro screen does not

exist)

#2=1: [CUSTOM](MENU screen) key is assigned for start

(No.8652#7 must be set to 1 in case macro screen does not

exist)

#3=1: Blank key is assigned for start

(No.8652#4 must be set to 1)

(2) Set following parameters for displaying load meter. Following

parameters depend on machining configuration. Refer to

Parameter Manual (B-63530EN) for detail.

No. Value note

1023 ≠0 Servo axis number of control axis

2086 ≠0 regular current parameter

2165 ≠0 maximum value of amplifier current

3151-3158 ≠0 Axis number to display load meter (Note)

4127 ≠0 Displayed value in maximum load

NOTE

In Series 30i, there are not the parameters from

No.3154 to No.3158.

(3) Set following parameters for optimizing cycle menu and icons of

Turning Cycle and Milling Cycle functions according to machine

configuration. In case of no above cycle options, it is unnecessary

to set.

No. Value note

14702#0 → 0:Vertical, 1:Horizontal for icons

27003#1-#0 →

Xxxxxx01: 3 axes (XYZ) Machining Center

xxxxxx10: 5 axes (XYZCB) Machining Center

27103#7,#3-#0 0xxx0000 0xxx0000: Machining Center

* In case 27003= xxxxxx00 & 27103=0xxx0000, all of cycle menu is

displayed

* This parameter is available on BY40/04 and later.

NOTE

When the parameter No.27003 or No.27103 is set,

please sure to push [F] key on NOW LOADING

screen after Power ON. The necessary parameters

are set automatically. (When the necessary

parameters are set, the message of “NOW

SETTING PARAMETERS” is displayed on the left

below of NOW LOADING screen.)
