Manual Guide i Operators manual Page 314

Operators manual
18.HANDLING LARGE PROGRAMS OPERATION B-63874EN/05
- 292 -
18.2 HANDLING A PROGRAM LARGER THAN THE MAXIMUM
ALLOWABLE SIZE
If the size of a program calculated according to the formula below
exceeds the maximum allowable memory size set in parameter No.
14795, the program cannot be handled on MANUAL GUIDE i.
Calculated size = (18 bytes)×(total number of blocks)+((number of
program characters)×1.1)
A program larger than the maximum allowable size is handled as
described below.
(1) If the screen display is switched from the NC screen to the MGi
screen
If the screen display is switched from the NC screen to the MGi
screen when a program larger than the maximum allowable
memory size is selected, the screen described below appears.
All MGi operations are disabled. Only switching to the NC
screen with the function key is enabled.
(2) If a selection is made on the program list screen
If a program larger than the maximum allowable memory size is
selected with the cursor and the [OPEN] soft key is pressed on
the program list screen, the [PROGRAM EXCEED MAXIMUM
SIZE.] message is displayed in the message display field on the
program list screen and the selection of the program is disabled.
CAUTION
If the program list screen contains only those
programs that are larger than the maximum
allowable memory size, the program list screen
cannot be closed. In this case, create a program to
close the program list screen.
(3) If an O search is made
<1> If the program number of a program larger than the
maximum allowable memory size is entered into the key-in
buffer, and the [O SRCH] soft key is pressed, the
[PROGRAM EXCEED MAXIMUM SIZE.] message is
displayed in the message display field on the base screen.
<2> If the program number of a program larger than the
maximum allowable memory size is not entered into the
key-in buffer, but the [O SRCH] soft key is pressed, the
program is not searched for.
