2.SIMULTANEOUS ALL PATH DISPLAY / EDITING FUNCTION MULTI-PATH LATHE FUNCTIONS B-63874EN/04

- 596 -

2.4 HOW TO SELECT PATH

Select the target path using [CHPATH] or path selection signal. As for

the selected path, the title of position and program display part is

displayed in blue. (As for the not selected path, the title will be

displayed in light blue.)

For the selected path, a similar operation system to the normal screen

is supported.

(In case of the screen which is not supported all path display mode,

the single path display mode will be selected automatically.)

2.5 OTHERS

• The screen which need full size, like animation, convert to nc

program, process list edit, chsize, and so on, will change to full

screen display automatically.

• It is impossible to operate for the not selected path.

• In 3-path, actual spindle speed and actual feed rate is not

supported because the display area is too small.
