4. INTERFACE BETWEEN NC AND PMC

B–63505EN/02

180

Group

series

Address Signal nameSymbol

EOTNA F130#6 f f

EOTNB

F133#6 f f

EOTNC

Negative-direction overtravel signal (PMC axis control)

F136#6 f f

EOTND F139#6 f f

EOTPA F130#5 f f

EOTPB

F133#5 f f

EOTPC

Positive-direction overtravel signal (PMC axis control)

F136#5 f f

EOTPD F139#5 f f

EOV0 Override 0% signal (PMC axis control) F129#5 f f

EPN0 to EPN13 Expansion workpiece number serach signal

G024#0 to #7

G025#0 to #5

f f

EREND Read completionsignal for external data input F060#0 f f

ERS External reset signal G008#7 f f

ESBKA G142#3 f f

ESBKB G154#3 f f

ESBKC

Block stop signal (PMC axis control)

G166#3 f f

ESBKD G178#3 f f

ESEND Search completionsignal for external data input F060#1 f f

ESKIP Skip signal (PMC axis control) X1004#6 f f

ESOFA G142#4 f f

ESOFB G154#4 f f

ESOFC

Servo off signal (PMC axis control)

G166#4 f f

ESOFD G178#4 f f

ESTB Read signal for external data input G002#7 f f

ESTPA G142#5 f f

ESTPB G154#5 f f

ESTPC

Axis control temporary stop signal (PMC axis control)

G166#5 f f

ESTPD G178#5 f f

EXLM Stored stroke limit select signal G007#6 f f

EXRD External read start signal G058#1 f f

EXSTP External read/punch stop signal G058#2 f f

EXWT External punch start signal G058#3 f f

F1D F1-digit feed select signal G016#7 - f

FIN Completionsignal G004#3 f f

F FSCSL Cs contour control change completionsignal F044#1 f f

FSPPH Spindle phase synchronous control completion signal F044#3 f f

FSPSY Spindle synchronous speed control completionsignal F044#2 f f
