APPENDIX

B–63505EN/02

C. BOOT SYSTEM

347

The following table lists and explains error messages in alphabetical

order.

Message Description and required action

DELETE ERROR.

HIT SELECT KEY.

Cause An attempt to delete a file from flash ROM was unsuccessful.

Action Retry the deletion. If the second attempt also fails, the flash

ROM may have been damaged or destroyed. Replace the

flash ROM module.

DEVICE ERROR (CNC x) Cause An attempt to write data to flash ROM was unsuccessful.

Action Retry the write operation. If the second attempt also fails, the

flash ROM may have been damaged or destroyed. Repalce

the flash ROM module.

D–RAM OR S–RAM PARITY Cause Invalid data was detected in the RAM area.

Action If an attempt is made to back up a RAM not cleared even

once, this message is displayed, and the boot system may

stop.

DRAM PARITY OCCURED.

PLEASE POWER OFF

Cause A hardware or software error occurred.

Action Determine the procedure which causes the error, and report

it to FANUC together with the series and edition of the boot

software.

FILE SAVE ERROR.

HIT SELECT KEY.

Cause An attempt to write a file to a memory card was unsuccessful.

Action Check that the memory card is not damaged.

Note Check that the memory card’s battery is not exhusted, that its

circuitry has not been damaged, and that it is securely in-

serted into its slot.

FLASH MEMORY NO SPACE Cause There is insufficient free flash ROM to store the selected file.

Action Delete any unnecessary files from flash ROM.

FLASH ROM MODULE NOT EXIST.

HIT SELECT.

Cause The flash ROM module is not mounted on that CNC system.

Action Put the flash ROM module on the board.

FORMAT ERROR.

HIT SELECT KEY.

Cause The formatting of the memory card failed.

Action Only a memory card of the SRAM type can be used.

Check whether the memory card used is of the flash memory

type.

ILLEGAL FORMAT FILE Cause The selected file cannot be read into flash memory.

Action The selected file or the header information for flash ROM may

have been damaged or destroyed.

INCORRECT PASSWORD Cause Error in the password specification

Action Key in the correct password.

LOADING ERROR.

HIT SELECT KEY.

Cause An error occurred while loading data into flash ROM.

Action Do not touch the memory card while loading data.

C.3

ERROR MESSAGES

AND REQUIRED

ACTIONS
