3. DATA CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

102

The procedure (functions) for the MDI keyboard, screen character

display, and graphic display is shown below. (For details, see Chapters

3, 4, 8, and 9 of Part III.)

Function name Description

pl_pcmdi Switches PMCMDI screens, and signals a task waiting for a PMCMDI

event.

pl_pcmdi_wait Waits for a PMCMDI screen event.

pl_ncmdi Switches to the NC screen.

pl_mdikey Reads MDI keys.

pl_keydef Controls the key-in line.

pl_keysts Posts the code input by keys.

pl_fkey_ign Command to disable function key input

pl_fkey_avil Command to enable function key input

pl_fkey_sts Posts function key input.

pl_dspclr Clears all CRT character screens.

pl_dspclrl Clears characters on the CRT screen in units of lines.

pl_dspclrc Clears characters on the CRT screen in units of columns.

pl_dsppos Specifies where to display characters on the CRT screen.

pl_dspcolor Specifies the color of characters on the CRT screen.

pl_dspattr Changes the attribute of characters on the CRT screen.

pl_dspstr Displays alphanumeric characters on the CRT screen.

pl_dspstrw Displays kanji, hiragana, and other special characters on the screen.

pl_dsptrblr Displays characters in triple size on the CRT screen.

pl_cursor Displays the cursor on the CRT screen.

pl_dspopen Initializes the CRT character display screen (9′′ CRT: 16 rows 40

columns, 14′′ CRT: 25 rows 80 columns).

pl_dspopen2 Initializes the CRT character display screen (14′′ CRT: 27 rows 74

columns).

pl_dspopen3 Initializes the CRT character display screen (14′′ CRT: 27 rows 80

columns).

pl_dspchar Displays the CRT character display position, display attribute, and

character string.

pl_dspsave Saves the CRT characters.

pl_dspresave Restores the CRT characters.

pl_dspcntl Specifies CRT display control.

pl_grpopen Initializes graphics on the CRT screen.

pl_grpclose Terminates graphics on the CRT screen.

pl_grpclr Erases graphics on the CRT screen.

pl_grpdspon Temporarily erases graphics on the CRT screen then re-displays

them.

pl_grplntyp Specifies the line type for graphics on the CRT screen.

pl_grpcolor Specifies the color for graphics on the CRT screen.

pl_grpline Draws a straight line on the CRT screen.

pl_grparc Draws an arc on the CRT screen.

pl_paint Paints out a figure on the CRT screen.

pl_grpopen2 Initializes graphics on the CRT screen.

(14′′ CRT: 432 dots 594 dots)

pl_grpsft Shifts a graphic figure on the CRT screen.

pl_grparc Posts whether graphic data on the CRT screen is valid.
