B–61863E–1/06

3. DATA CONTROL FUNCTION

PMC CONTROL SOFTWARE

121

By using the NC window function (pl_nc_windr(), pl_nc_windw()), a

window data between PMC and NC can be read and written.

(1) Data read from NC

Function No. Description Type *1

13 Reads tool offset value Low

15 Reads workpiece origin offset High

17 Reads parameter data and reads setting data Low

21 Reads custom macro variables Low

23 Reads CNC alarm information Low

24 Reads the executing program number Low

25 Reads the executing sequence number Low

26 Reads the actual speed of the controlled axis Low

27 Reads absolute position of the controlled axis High

28 Reads the machine coordinates of the controlled axis High

29 Reads the skip position of the controlled axis Low

30 Reads the servo delay of the controlled axis High

31 Reads the acceleration/deceleration delay High

32 Reads modal data Low

33 Reads diagnostic data Low

34 Reads the load current of feed motor and A/D conver-

sion data

High

38 Reads tool life management data (tool group numbers) Low

39 Reads tool life management data (number of tool

group)

Low

40 Reads tool life management data (number of tools) Low

41 Reads tool life management data (tool life) Low

42 Reads tool life management data (tool life counter) Low

160 Reads tool life management data (tool life counter type) Low

43 Reads tool life management data (tool length com-

pensation No.1: tool No.)

Low

44 Reads tool life management data (tool length com-

pensation No.2: tool use order)

Low

45 Reads tool life management data (cutter compensation

No.1: tool No.)

Low

46 Reads tool life management data (cutter compensation

No.2: tool use order)

Low

47 Reads tool life management data (tool information

No.1: tool No.)

Low

48 Reads tool life management data (tool information

No.2: tool use order)

Low

49 Reads tool life management data (tool No.) Low

151 Reads clock data Low

74 Reads the relative position of the controlled axis. High

75 Reads the remaining travel of the controlled axis. High

211 Reads the estimate disturbance torque data High

178 Reads the machining time. Low

153 Reads the load current for the spindle motor High

213 Reads tool offset data according to specified tool num-

ber.

Low

212 Reads pulse count module data. High

200 Reads tool life management data (tool group num-

bers)(for tool number 8–digits)

Low

227 Reads tool life management data (tool length com-

pensation No.1: tool No.) (for tool number 8–digits)

Low

228 Reads tool life management data (cutter compensation

No.1: tool No.) (for tool number 8–digits)

Low

201 Reads tool life management data (tool information

No.1: tool No.) (for tool number 8–digits)

Low

321 Reads real type data in NC parameter Low

3.3.5

NC Window
