8. CRT CHARACTER DISPLAY

B–61863E–1/06

PMC LIBRARY

226

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f f f f

[Name]

pl_dspchar

[Description]

Displays a series of character strings with the specified display

position and display attribute.

[Format]

ret = pl_dspchar(P1) ;

short ret ;

short *P1 ;

[Input]

*P1 Display information

XXXX

S : Display format

S=1 : Single-size character display code

Character string to be displayed in the area for one

character, such as alphanumeric characters

S=2 : Double-size character display code

Character string to be displayed in the area for two

characters, such as Kanji, Hiragana (JIS code), and

special characters

S=3 : Triple-size character display code (only for

alphanumeric characters, sign (–), and period (.))

S=4 : Single-size and double-size character display codes used

in combination

Single-size character code such as alphanumeric

characters (ASCII code) and double-size character code

such as Kanji and Hiragana (shift JIS code)

S=5 : Graph character code (85H to 8FH)

Code 85H

Char.

86H 87H 88H 89H 8AH 8BH 8DH 8EH 8FH8CH

All other codes display spaces.

8.14

DISPLAYING THE

CHARACTER STRING

WITH THE SPECIFIED

DISPLAY POSITION

AND DISPLAY

ATTRIBUTE

N–1

N : Display data size(*1)

A : Display attribute

S : Display format

X : Display column position

Y : Display line position

S=2

Display

data

section
