9. C-PROGRAM MEMORY DISPLAY

AND DEBUG FUNCTION

B–61863E–1/06

APPLICATION

PROGRAMMING GUIDE

438

DESCRIPTOR TABLE MAP

TABLE = GDT BASE = 00845000H LIMIT = 012FH

TABLE INDEX SELECTOR DESCRIPTOR NAME

1 0008H ?SEGMENT.1

2 0010H ?SEGMENT.2

32 0103H ?SEGMENT.3

33 010BH ?SEGMENT.4

→ * c

34 0113H ?SEGMENT.5

35 011BH ?SEGMENT.6

36 0123H ?SEGMENT.7

37 0128H ?386TASK.1

SYMBOL MAP

MODULE = DEMO

PUBLIC NAME BASE OFFSET TYPE WC ABSOLUTE ADDRESS

→ * d

F_DSPSAVE. . . GDT(35) 0010H INTEGER(2) 0 00000014H

F_GRPOPEN. . . GDT(35) 0012H INTEGER(2) 0 00000016H

SYS......GDT(35) 0000H INTEGER(2) 0 00000004H

→ * e

MAIN.....GDT(34) 0774H PROCEDURE FAR16 0 00845A7CH

(1) As the break address (BREAK SEG.ADR), set the address of the area

used by a user C program. If the address of the area used by the PMC

control software is specified, a break request may cause a system

hang-up.

(2) This function uses the debugging function incorporated into the CPU.

When the debugging function is used, the processing speed of the

CPU decreases. Avoid using the function during normal operation.

Use it only for debugging.

9.3.7

Notes
