G. HINT FOR MAKING LINK CONTROL

STATEMENT, COMMAND FILE

FOR BINDER, BUILD FILE

B–61863E–1/06

APPENDIX

534

3) Setting of the common memory

COMMON MEMORY COUNT = 1

( 0:NOTHING / 1  8 )

On the main screen of MKC (Link control statement creation

tool), specify the amount of segment for common memory.

If common memory is not used, specify 0.

MEMORY GDT ENTRY

MEMORY GDT ENTRY NO. 1 = 36

On common memory definition screen of MKC(Link control

statement creation tool), specify the entry of common memory.

Specify like as the data segment setting in the section b.2).

c. Specification of the segment name for binding

At the part of **** of “RN(CODE TO ****, DATA TO ****)” in

command file for binder, specify the segment name which is declared

in build file as a code/data segment.

Segment name is renamed at the binding.

Example) RN(CODE TO TASK1_CODE

, DATA TO TASK1_DATA)

CAUTION

Specify the data segment whose entry is specified in Link

control statement at b.2) to the data segment.
