11. NC WINDOW LIBRARY

B–61863E–1/06

PMC LIBRARY

280

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f f f f

[Name]

pl_nc_windw

[Description]

function to write window data from the NC.

[Format]

ret = pl_nc_windw(P1) ;

short ret ;

short *P1 ;

[Input]

*P1 Window library information

The values of the function code, data length, data number, data

attribute, and data area need to be specified according to the window

data to be written.

[Output]

______

[Returns]

ret Complete code (–10, –1, 0, 1, 2, 3, 4, 5, 6, 7)

[Remarks]

For the return values, see the section on completion code types.

For details on writing window data between the PMC and NC, see

Appendix B, “PMC-PA1 / PA3 / SA1 / SA2 / SA3 / SA5 / SB / SB2

/ SB3 / SB4 / SB5 / SB6 / SC / SC3 / SC4 / NB / NB2 /NB6 (LADDER

LANGUAGE) Programming Description.”

The length of the window data area depends on the window type.

11.2

WRITING WINDOW

DATA FROM THE NC

Function code

(Complete code)

Data length

Data number

Data attribute

Data area
