B–61863E–1/06

10. READER/PUNCHER INTERFACEPMC LIBRARY

271

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f f f f

[Name]

pl_rswrt2

[Description]

Sends data through the reader/puncher interface. This function cannot

be used when the interface has been opened in the data input mode

(OP=11 or 12).

[Format]

ret = pl_rswrt2(P1,P2,P3) ;

short ret ;

short P1 ;

char *P2 ;

unsigned short P3 ;

[Input]

P1 Specifying the channel to output

1 : channel 1

2 : channel 2

*P2 Output character string

’X’

P3 Size of output character string (The maximum size is 256 bytes)

[Output]

______

[Returns]

ret Completion code (0, 1, 2, 5, 6, 20, 22)

[Remarks]

For the return value, see the item on the completion code types.

10.11

OUTPUTTING DATA

THROUGH THE

READER/PUNCHER

INTERFACE

N–2

N–1

Specify it in ASCII code. The actual output code is

determined by the OC value specified with pl_rsopen2() and

pl_fopen2(). When OP is set to 1 or 2, the specified data is

directly output.
