B–61863E–1/06

3. DATA CONTROL FUNCTION

PMC CONTROL SOFTWARE

109

[How to handle soft keys]

Codes F0 to F9, FR, and FL are codes for soft keys. The correspondence

between the key codes and the MDI keyboard is shown below.

(For a 9-inch CRT) F0 to F4, FR, and FL

(For a 10-inch LCD or 14-inch CRT) F0 to F9, FR, and FL

[ ] [ ] [ ] [ ] [ ]

“FL”“F4”“F3”“F2”“F1”“F0” “FR”

“FL”“F9”“F8”“F7”“F1”“F0”“FR”

(3) CRT character display screen

The character display functions provide a coordinate system which

locates the position of any character on the screen.

The upper left corner of the screen is the origin. Starting from the

origin, the horizontal line is the positive X–axis and the vertical line

is the positive Y–axis. On FS16i /18i /21i , screen size is 30 rows and

80 columns. On FS15B, screen size is 27 rows and 80 columns. On

FS15i–A, to keep the compatibility with FS15B, origin is set as X=0

and Y=3 in default. The horizontal line is the positive X–axis and the

vertical line is the positive Y–axis. If pl_dspopen4() function

described later is called, the upper left corner (X=0,Y=0) is set as

origin and the function initializes the all of screen (30 rows and 80

columns).

If initialization by PMC control software should be canceled, set bit

7 of PMC address K18 or K901(keep relay) to on.

In this case, the application program must perform initialization using

pl_dspopen, pl_dspopen2, pl_dspopen3 or pl_dspopen4 function

with FS16i/18i/21i. Application program must perform initialization

using pl_dspopen3 or pl_dspopen4 function with FS15i–A. For

details of pl_ dspopen3, pl_dspopen4 function, please refer to Part III.

When the PMCMDI screen is switched to a non–PMCMDI screen,

the PMC control software clears the screen.

For details of character display function, please refer to Part III.
