2. TASK CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

(1) Priority

In the PMC control software, the execution priority of ladder

programs, PMC screen display, and C programs is as follows:

First-level ladder program > Second-level ladder program >

highest-priority C program > PMC screen display > C program tasks

In this manual, PMC screen display refers to displaying PMC

diagnostic screens and PMC built-in programmer function screens.

Priority

High

First–level ladder program

Second–level ladder program

Low

C program tasks

(priority 10 to 99)

Task 1, third–level ladder program

Task 2

Task n

Highest–priority C program

PMC screen display

(NOTE1)

(NOTE2)

(2) C program processing time

The processing time for a C program is determined according to the

LADDER EXEC ratio set on the system parameter screen of the PMC

programmer function.

For example, if LADDER EXEC is set to 100%, in each 8 ms cycle,

5 ms is allotted to the processing of the first-level and second-level

ladder programs (*a), and the remaining 3 ms is allotted to PMC

screen display and C program processing (*b to *d).

[Setting range of LADDER EXEC]

D 40% to 150% (2 ms to 7.5 ms) in the ladder division method

D 40% to 120% (2 ms to 6 ms) in the ladder non-division method

0 8 16 24 (ms)

*b to *d

2.7

RELATIONSHIP

BETWEEN LADDER

PROGRAMS AND C

PROGRAMS

2.7.1

PMC-SC/SC3/SC4/NB/

NB2
