PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 130

Programming manual

Page of 619

/ 619

3. DATA CONTROL FUNCTION

B–61863E–1/06

PMC CONTROL SOFTWARE

114

When a character is sent, the present display position indicates its display

position. The present display position is updated according to whether the

character is positioned halfway or at the right end as shown in the

following table.

Character

X coordinate Y coordinate

Character

size

An intermediate

position

Right end

An intermediate

position

Right end

Normal size

character

Added by +1 Returns to 0 No change occurs. Added by +1

“Kanji” Added by +2 Returns to 0 No change occurs. Added by +1

Triple

character

Added by +3 Returns to 0 No change occurs. Added by +2

NOTE

1 It is impossible to display “kanji” or triple characters at the

position where the residual columns are insufficient at the

right end.

2 The following characters can be made triple size: 0 - 9, A-Z,

-, . and space.

3 See Appendix A for the correspondence between

displayable “Kanji” and their codes.

4 See III–8.6 for how to specify the display attributes.

(4) CRT graphic screen

In graphic display control, there is a coordinate that shows which

position on the screen is to be displayed.

With the center of the screen as the origin, the +X direction is toward

the right of the screen and the +Y direction is toward the top of the

screen.

To draw graphics on the PMCMDI screen, the application program

must initialize the graphic display using the system all, pl_grpopen.

When the PMCMDI screen is switched to a non-PMCMDI screen, the

screen is cleared by the PMC control software.

(For 9-inch CRT, 14-inch CRT, and 10-inch LCD)

PMC–SC/SC3/SC4

Y coordinate

X coordinate

(0, 199)

(0, 0)

(–320, 0) (319, 0)

(0, –200)

PMC–NB/NB2

Y coordinate

X coordinate

(0, 215)

(0, 0)

(–295, 0) (295, 0)

(0, –215)
