I. CONVERSION FROM FS15B TO FS15iA

B–61863E–1/06

APPENDIX

550

The files listed below are used for FS15B and FS15iA. The same file

names are used, but there is no object code compatibility. So, use the files

for FS15iA (those files that are placed in the directory named LIB.15i and

INC.15i).

–

pmc.lib

– pmc2.lib

– pmclib.h

D As a library for floating–point operations, the following file is added:

–

pmc3.lib

D As a tool for conversion to the memory card format, the file below is

added. This file is not compatible with FS16i. Use the file for FS15iA.

– hex2mem.exe

The library floppy data is structured as shown below.

ŅINC.15B Header file for FS15B

ŅINC.15i Header file for FS15iA

ŅKEEPMEM

Ņi_seires Link control statement and so forth for FS15iA

ŅNB

ŅRC

ŅLIB.15B Library for FS15B

ŅLIB.15i Library for FS15iA

ŅNCPROG

Ņi_series Link control statement and so forth for FS15iA

ŅNB

ŅRC

ŅSAMPLE

ŅTOOL

Ņhex2mem .15i Memory card conversion tool

ŅPC98

ŅPCAT

ŅTUTORIAL

Ņ5–2

Ņ5–3

Ņi_seires Link control statement and so forth for FS15iA

ŅNB

ŅRC

Ņ5–4

Ņi_seires Link control statement and so forth for FS15iA

ŅNB

ŅRC

I.4

FILE COMPATIBILITY
