12. NC COMMAND PROGRAM (PMC-SC)

B–61863E–1/06

PMC LIBRARY

300

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f  f 

[Name]

pl_nc_pdirstart

[Description]

Executes processing to start reading the numbers of all machining

programs registered in the NC.

[Format]

ret = pl_nc_pdirstart(P1,P2) ;

short ret ;

short P1 ;

short *P2 ;

[Input]

P1 Data number 00H : Read program numbers.

01H : Read program numbers and comment

character strings.

*P2 Read program information

First program number to be

read

Last program number to be

read

[Output]

______

[Returns]

ret Complete code (–1, 0, 3, 5)

–1 : The request to start inputting the list of program numbers has

been rejected. This completion code is returned when the

command is issued while the NC is in the background edit

mode, download mode, or check mode.

0 : Processing to start inputting the list of program numbers has

normally terminated.

3 : The data number is incorrect.

5 : The data of the program for the number specified is incorrect.

[Remarks]

______

12.17

EXECUTING

PROCESSING TO

START INPUTTING

THE LIST OF

PROGRAM

NUMBERS

· When 0 is specified as the first program

number, data of all registered programs is

read starting from the first program.)

· When 0 is specified as the last program

number, data of all registered programs

including the last one is read.
