PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 513

Programming manual

Page of 619

/ 619

B–61863E–1/06

D. EXAMPLES OF PROGRAMSAPPENDIX

497

/*==============================================================*/

/* mail man task–1*/

/*==============================================================*/

#include <pmclib.h>

long tim ;

unsigned long lo;

unsigned long hi ;

void far test_tsk1()

{

char *adr,*adrlo,*adrhi ;

short i,pos[2],col[2] ;

col[0]=0xe0 ; col[1]=0 ;

os_make_mbx(10,5) ;

pl_pcmdi_wait() ;

pl_dspcolor(col);

for( i=0,pos[1] =0;i!=5;i++,pos[1]++ ){

os_read_mbx(10,(long)1000,(unsignedlong *)&adr) ;

pos[0] = 0 ;

pl_dsppos(pos) ;

pl_dspstr(0x18,adr,100) ;

os_red2_mbx(10,(long)1000,(unsignedlong *)&adrlo,

(unsigned long *)&adrhi) ;

pos[0] = 10 ;

pl_dsppos(pos) ;

pl_dspstr(0x18,adrlo,100) ;

pos[0] = 23 ;

pl_dsppos(pos) ;

pl_dspstr(0x18,adrhi,100) ;

}

/*==============================================================*/

/* mail man task–2*/

/*==============================================================*/

#include <pmclib.h>

char const * const dsp[]={ ”MBX -1-”,”MBX -2-”,”MBX -3-”,”MBX -4-”,

”MBX -5-”};

char const * const dsplo[]={”MBX LO -1-”,”MBX LO -2-”,”MBX LO -3-”,

”MBX LO -4-”,”MBX LO -5-”};

char const * const dsphi[]={”MBX HI -1-”,”MBX HI -2-”,”MBX HI -3-”,

”MBX HI -4-”,”MBX HI -5-”};

short dummy_data ;

void far test_tsk2()

{

short i ;

pl_pcmdi_wait() ;

for( i = 0 ; i != 5 ; i++ ){

os_writ_mbx(10,(long)0,(unsigned long)dsp[i]) ;

os_wrt2_mbx(10,(long)0,(unsigned long)dsplo[i],

(unsigned long)dsphi[i]) ;

}
