6. EXECUTION FILE CREATION

B–61863E–1/06

APPLICATION

PROGRAMMING GUIDE

414

EXECUTION FILE CREATION

An execution file is created from a C source file as described below:

NOTE

For detailed explanations on compiling, binding, and

building, refer to the below manuals.

“iC-86/286 Compiler User’s Guide”

“Intel386 Family Utilities User’s Guide”

“Intel386 Family System Builder User’s Guide”

(1) The C source file is compiled.

[Compile format]

IC286 TASK1.C PR(TASK1.LIS) COMPACT EXTEND ROM

TASK1.C : C source file name

PRINT(PR) : Specification of compile listing output file name

COMPACT(CP) : The compact model is specified for segment

memory. (DS and SS are separate.) The default

is all near-types with only data pointers set as

far-types (selector + offset). When /COMPACT,

the code segment name is “CODE” and the data

segment name is “DATA”.

EXTEND(EX) : Expansion of the IC286 compiler (far format etc.

can be used).

ROM : The constant is taken by the code segment. If it

is not attached, the constant is taken by the data

segment and the value will be undefined at the

time of execution.

CAUTION

1 COMPACT, EXTEND, and ROM must be specified.

(The abbreviated form is indicated in parentheses.)

2 The prototype declaration of the PMC library function is in

the PMCLIB.H include file. When the prototype declaration

is not used, the NARGS symbol must be defined with

#define in the source program or compile option.

IC286 TASK1.C PR(TASK1.LIS) COMPACT EXTEND

ROM DEFINE(NARGS)

3 When it is necessary to find a program break address with

the debug function (described later), specify ”CODE” to

output a machine code listing.

IC286 TASK1.C PR(TASK1.LIS) COMPACT EXTEND

ROM CODE
