PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 553

Programming manual

Page of 619

/ 619

B–61863E–1/06

G. HINT FOR MAKING LINK CONTROL

STATEMENT, COMMAND FILE

FOR BINDER, BUILD FILE

APPENDIX

537

D TASK COUNT (Link control statement)

On the main screen of MKC(Link control statement creation tool),

specify amount of the C application task(except the 3rd level of

LADDER).

D ENTRY ADDRESS NAME (Link control statement)

ENTRY ADDRESS NAME = smpl_tsk1

On the task information definition screen of MKC(Link control

statement creation tool), specify name of the task entry function(main

function of the task).

This is a pointer to the function, so please remove ’()’ after the function

name.

Please specify the correct name.

CAUTION

Please declare the entry function with far qualifier in the

source file (*.c).

Please make the entry function public on binding.

(specify the option “NOPL EC (entry function)” or “PL”)

D STACK SIZE(Link control statement)

On the task information definition screen of MKC (Link control

statement creation tool), specify amount of the stack used by a task.

Please refer the Appendix B for getting the size of stack.

D TASK NAME (Link control statement)

Specify the name of task which is displayed on USRDGN screen

(PMCDGN).

Max. 8 character of upper–case alphabet and number are available.

D Setting of command file for binder

Example)

CTL.OBJ, &

TASK1.OBJ, &

PMC2.LIB, &

CLIB2C.LIB &

OJ(TASK1.LNK) NOLO NOPL EC(SMPL_TSK1) &

PR(TASK1.MP1) NAME(TASK1) SS (STACK(0)) &

RN(CODE TO TASK1_CODE,DATA TO TASK1_DATA)

D When description continues to the next line in command file for

binder,

put ’&’ to the last of the line.

D Please put ’,’ as delimiter if there are several files to bind. ’,’

following the last file is not needed.

D Please bind PMC2.LIB and CLIB2C.LIB for each task.

Please specify PMC2.LIB before CLIB2C.LIB to the file.

Please bind PMC.LIB at entire binding.

D Stack size must be specified to 0 (Specify “SS (STACK (0) )”).

(Because PMC system software allocates the stack by the setting

of link control statement)

G.6

SETTING OF THE

OTHERS
