9. GRAPHICS DISPLAY

B–61863E–1/06

PMC LIBRARY

252

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

f  f 

[Name]

pl_grppalette

[Description]

Sets the all color palette for VGA graphic display.

[Format]

ret = pl_grppalette(p1);

short ret;

long *p1

[Input]

*p1 Palette information

Color information

R value, G value and B value of the color palette are set

respectively as follows. Each value can specify from 0 to 3FH.

Please do not change the setting of palette 0(Please always

input 0).

4 byte 3 byte 2 byte 1 byte

Always 0 B value G value R value

[Output]

______

[Returns]

ret Completion code (–11, –1, 0)

[Remarks]

For the return value, see the item on the completion code types.

This function is effective only in VGA.

9.14

SETTING COLOR

PALETTE FOR VGA

GRAPHIC DISPLAY

Color information of palette 0 (always 0)

Color information of palette 1

Color information of palette 14

Color information of palette 15
