B–61863E–1/06

2. DETERMINING

THE SPECIFICATIONS

OF THE C PROGRAMS

APPLICATION

PROGRAMMING GUIDE

395

When the size of the area for Ladder programs is changed from 96KB

to 72KB, the area is allocated as shown below:

MAX LADDER SIZE=96KB MAX LADDER SIZE=72KB

168000H

Data area for C

programs (about 64KB)

180000H

16E000H

180000H

NOTE 1

NOTE 2

Ladder programs

(96KB)

NOTE 2

Ladder programs

(72KB)

Data area for C programs

(about 88KB)

NOTE

1 The first address of the data area for C programs is not

always set to a specific address.

2 The area used by the PMC management software.

3 The PMC management software automatically allocates

data areas (a) and (b) using the segment limit value

specified in the GDT entry by the link control statement

creation tool. It automatically allocates data area (c) using

the stack size specified by the link control statement

creation tool. Therefore, it is not necessary for the

application to be aware of specific addresses.
