1. GENERAL
B–61863E–1/06
PMC LIBRARY
140
No. 15i-A16i/18i/21iNB/NB2RC/RC3/RC4DescriptionFunction name
12.23 pl_nc_vrfstart2 Executes processing to start outputting the
data of the NC command to be verified.
(Corresponding to TT)
f f
12.24 pl_nc_verify2 Outputs the data of the NC command to be
verified. (Corresponding to TT)
f f
12.25 pl_nc_vrfend2 Executes processing to terminate output-
ting the data of the NC command to be veri-
fied. (Corresponding to TT)
f f
12.26 pl_nc_dncstart2 Executes processing to start outputting the
data of the NC command to be used for
operation. (Corresponding to TT)
f f
12.27 pl_nc_dnc2 Outputs the data of the NC command to be
used for operation. (Corresponding to TT)
f f
12.28 pl_nc_dncend2 Executes processing to terminate output-
ting the data of the NC command to be used
for operation. (Corresponding to TT)
f f
12.29 pl_nc_search2 Searches for the specified NC program.
(Corresponding to TT)
f f
12.30 pl_nc_delall2 Deletes all NC programs. (Corresponding
to TT)
f f
12.31 pl_nc_delete2 Deletes the specified NC program. (Corre-
sponding to TT)
f f
12.32 pl_nc_upstart2 Executes processing to start inputting the
NC command data. (Corresponding to TT)
f f
12.33 pl_nc_upload2 Inputs the NC command data. (Corre-
sponding to TT)
f f
12.34 pl_nc_upend2 Executes processing to terminate inputting
the NC command data. (Corresponding to
TT)
f f
12.35 pl_nc_dir2 Inputs the NC program management data.
(Corresponding to TT)
f f
12.36 pl_nc_pdirstart2 Executes processing to start inputting the
list of NC program numbers. (Correspond-
ing to TT)
f f
12.37 pl_progdir2 Inputs the list of NC program numbers.
(Corresponding to TT)
f f
12.38 pl_nc_pdirend2 Executes processing to terminate inputting
the list of NC program numbers. (Corre-
sponding to TT)
f f
13.20 pl_nc_search_o8 Searches for a specified NC program. (for
program number 8–digits)
f
13.21 pl_nc_delete_o8 Deletes a specified NC program. (for pro-
gram number 8–digits)
f
13.22 pl_nc_upstart_o8 Executes processing to start inputting the
data of the NC command data. (for program
number 8–digits)
f
13.23 pl_nc_pdirstart_o8 Executes processing to start inputting the
list of NC program numbers. (for program
number 8–digits)
f
f: Supported, : Not supported
Functions for accessing the MMC window
No. Function name Description RC/RC3/RC4 NB/NB2 16i/18i/21i 15i-A
14.1 pl_mmcwr Reads the window data from MMC. f f f
14.2 pl_mmcww Writes the window data into MMC. f f f
