PMC-MODEL SC/SC3/SC4/NB/NB2 (C Language Programming) Programming manual Page 619

Programming manual
FANUC PMC C Language function
Supplemental Programming Manual
01 05.01.26
Ino
New registration
B-61863E-1/06-4
EDIT
DATE
DESIG.
DESCRIPTION
5/5
DRAW.NO.
3 EXPANDED NONVOLATILE MEMORY
Add the following “NOTE” to “II PMC CONTROL SOFTWARE, 3.4 EXPANDED NONVOLATILE
MEMORY”:
Replace “Remarks” of “III PMC LIBRARY, 7.1 READING DATA FROM EXPANDED NONVOLATILE
MEMORY”:
[Remarks]
Maximum size of data which can be treated at one time is 64KB
because the reading data size is specified by 2-byte unsigned integer.
Refer to the note of “II-3.4 EXPANDED NONVOLATILE
MEMORY”.
Replace “Remarks” of “III PMC LIBRARY, 7.2 WRITING DATA INTO EXPANDED NONVOLATILE
MEMORY”:
[Remarks]
Maximum size of data which can be treated at one time is 64KB
because the writing data size is specified by 2-byte unsigned integer.
Refer to the note of “II-3.4 EXPANDED NONVOLATILE
MEMORY”.
N
OTE)
N
ote the following points when specifying the option of expande
d
nonvolatile memory in which data size exceeds 64KB.
(1) A memory area whose data size exceeds 64KB can not be
allocated in data segment or common memory of PMC C
language application. Therefore, the following can not work.
- Can not read data of the nonvolatile memory whose data size
exceeds 64KB and save the data to one memory area.
- Can not prepare data whose size exceeds 64KB in one
memory area in advance for writing .
In such cases, make the application which treats the data withi
n
the maximum size of 64KB.
(2) All data of the expanded nonvolatile memory can not be read
and written at once. Maximum size of data which can be treate
d
at one time is 64KB.
