5. PMC ADDRESS ACCESSPMC LIBRARY

197

SC/SC3/SC4 NB/NB2 16i/18i/21i 15i–A

 f  f

[Name]

pl_rdcntldata

[Description]

Reads a control data of PMC data table.

[Format]

ret = pl_rdcntldata(s_number, e_number, length, buf)

short ret;

short s_number;

short e_number;

short length;

short *buf;

[Input]

s_number Start group number to read

e_number End group number to read

length Size of data buffer(8 m+6, m:group number)

[Output]

*buf Control data of data table

datano_s

dummy

datano_e

tbl_prm

data_type

data_no

data_adr

tbl_prm

data_type

N–8

N–6

N–4

N–2

Start group number (s)

(not used)

End group number (e)

Table parameter of group “s”

Data type of group “s”

Data number of group “s” (byte)

Top address of group “s”

Table parameter of group “e”

Data type of group “e”

Data number of group “e” (byte)

Top address of group “e”

buf

data_no

data_adr

[Returns]

ret

0 : Normal termination

3 : Start group number or end group number to read is

incorrect.Size of data buffer is incorrect.

[Remarks]

Please refer the following manual for the detail of output data.

FANUC PMC MODEL PA1 / PA3 / SA1 / SA2 / SA3 / SA5 / SB / SB2

/ SB3 / SB4 / SB5 / SB6 / SC / SC3 / SC4 / NB / NB2 / NB6 LADDER

LANGUAGE PROGRAMMING MANUAL (B–61863E)

5.7

READING A DATA

TABLE CONTROL

DATA
